SD100i
Number of tester channels: 10 Memory: 64MB (8 million points)
Acquisition Frequency: 0.05S~1800S Accuracy: ±0.3 ℃
Resolution: 0.1 ℃ Operating voltage: DC3.7-4.2V
Battery: 450mAH Thermocouple type: K type
Instrument power consumption: ≤15mAH Maximum internal working temperature: 85 ℃/100 ℃
Classification:
Temperature Profiling
Key words:
密度
Contact Us
Product Description
Technical characteristics
software functionality
*Real-time measurement *Thermometer board management and statistics function
*Curve data import and export function *Curve trimming function
*Curve import and merge comparison function *Draw horizontal and vertical lines at will
*Download benchmark comparison function *Curve simulation (curve simulation)
*Curve data export PDF, EXCEL *SPC analysis
*Furnace parameters and process binding, download the selection of linkage
*Record the temperature at each point and show it through the curve
*Slope and time change of temperature above or below any point.
*Slope and time change between any two points
